Manual
Ch
En
Input 6V~14.8V
Output 12A / 7.2V (MAX 86W)
BEC Data 5V 2A
Peak / continuous 20A / 12A
P.W.M 9.5 kHz
weight 8.7g
Dimension 24x15.5x6.5(LxBxHmm)
　

Manual
Ch
En
Input 6V~14.8V
Output 15A / 7.2V (MAX 108W)
BEC Data 5V 2A
Peak / continuous 20A / 12A
P.W.M 9.5 kHz
weight 12.2g
Dimension
(LxBxHmm)		 23.5x23.5x6.5
(LxBxHmm)
　

Manual
Ch
En
Input 6~14.8V
Output 25A / 7.2V (MAX 180W)
BEC Data 5V 2A
Peak / continuous 30A / 25A
P.W.M 9.5kHz
weight 23.6g
Dimension 38x24x6(LxBxHmm)
　

Manual
Ch
En
Input 6V~14.8V
Output 25A / 7.2V (MAX 180W)
BEC Data 5V 2A
Peak / continuous 38A / 28A
P.W.M 9.5kHz
weight 28g
Dimension 38x24x6(LxBxHmm)
　

Manual
Ch
En
Input 6V~14.8V
Output 40A / 7.2V (MAX 288W)
BEC Data 5V 2A
Peak / continuous 60A / 40A
P.W.M 9.5kHz
weight 35g
Dimension 55x35x10(LxBxHmm)
　

Manual
Ch
En
Input 6V~14.8V
Output 55A / 7.2V (MAX 396W)
BEC Data 5V 3A
Peak / continuous 72A / 55A
P.W.M 9.5kHz
weight 43g
Dimension 68x26.6x12.8(LxBxHmm)
　
　
　
　
